AG Gyrocopters - Two Models
Spartan Airframe Kit: $94,500
🧩 What’s Included in the Kit?
Each Spartan Airframe kit includes:
✅ Fully molded composite monocoque fuselage
✅ Complete control system (dual joysticks, pedals, linkages. Best for training.)
✅ Landing gear system with mounts and brake support
✅ Rotor mast and rotor head (without blades)
✅ Tail section with stabilizers, rudder, and elevator
✅ Electrical harness (pre-installed, ready to configure)
✅ Composite fuel tanks (120-liter capacity)
✅ Complete doors, hatches
✅ Interior frame (no upholstery – ready for your own finish)
✅ Central console with storage and cup holders
Early Orders Discounted Price: $93,300, with delivery starting March 2026.
Javelin Airframe Kit: $98,000
Each Javelin Airframe kit includes:
✅ Fully molded composite monocoque extended fuselage
✅ Complete control system (single joystick, pedals, linkages)
✅ Landing gear system with mounts and brake support
✅ Rotor mast and rotor head (without blades)
✅ Tail section with stabilizers, rudder, and elevator
✅ Electrical harness (pre-installed, ready to configure)
✅ Composite fuel tanks (120-liter capacity)
✅ Complete doors, hatches, and hinged front access
✅ Interior frame (no upholstery – ready for your own finish)
✅ Cargo compartment with over 300 liters of usable space
✅ Central console with storage and cup holders
Early Orders Discounted Price: $96,800, with delivery starting February 2026.
| Compare AG Javelin Pricing and Value to the Competition | |||
|---|---|---|---|
| Feature | AG Javelin | Magni M24 | Autogyro Cavalon |
| Cabin Width | 1.3 M (51") - largest in class. True side by side comfort | 1.1 M (43") | 1.1 M (43") |
| MTOW | 680 kg (1,499 lbs) - highest in its category | 560 kg (1,235 lbs) | 560 kg (1,235 lbs) |
| Empty Weight | 320 kg (705 lbs) with 915 engine, rotor/basic interior | ~295 kg (650 lbs) | ~295 kg (650 lbs) |
| Cargo Space | Rear Cargo + cabin storiage | Minimal | Minimal |
| Airframe Material | Certified carbon fibre composite + reinforced structure | Aluminum & composite mix | Aluminum & composite mix |
| Rotor System | Compatible with GyroTech high-performance, all-weather, composite rotor | Proprietary | Proprietary |
| Powerplant Options | Flexible - Rotax 915 / 916 or custom (e.g. Verner Radial) | Proprietary Rotax set-ups only | Proprietary Rotax set-ups only |
| Field Mainenance | Modular systems, easy panel access, low specialized tool requirement | Higher specialized support | Higher specialized support |
| Adaptability | Full kit option for LSA/BCAR/Custom Mission Builds | Factory Built Only | Factory Built Only |
| Price for Kit | From $98,000 USD | N/A (no kit option) | N/A (no kit option) |
| Fully Equipped Price | W/ Rotax 916: ~ $180,000 | $240,000 + | $230,000 + |
| Special Missions | Medevac, anti-poaching, surveillance, LIDAR, tourism | Limited | Limited |
Airgyro Aviation LLC
11085 S. Conestoga Drive, Spanish Fork, Utah 84660
